25-Year Manufacturer of Commercial Vehicle Safety Solutions

Home / All / NDVR / ND381 4-Channel AHD Hard Disk Vehicle Recorder with G-Sensor

ND381 4-Channel AHD Hard Disk Vehicle Recorder with G-Sensor

ND381 4-Channel AHD Hard Disk Vehicle Recorder with G-Sensor
Share
CategoriesNDVR
BrandAlwayCare Commercial Fleet Safety Manufacturer
Product SpecificationsND381
Channels4-channel AHD vehicle recorder
Video Input1080P/720P/CVBS mixed input; AHD/TVI cameras
Video EncodingH.264 / H.265
Recording1080P (1920x1080)
StorageSD card up to 512GB + 4TB SSD
Video OutputVGA + HDMI + CVBS
Alarm I/O4 alarm inputs, 2 alarm outputs
PositioningBuilt-in GPS / BeiDou / GLONASS (by version)
Network4G module and built-in WiFi (by version)
ProtocolJT808 / JT1078
SystemLinux
G-SensorBuilt-in
VersionsND381: local unit; -1 +GPS; -2 +GPS, WiFi; -3 and -4 +GPS, WiFi, 4G by region
Warranty15 Months
ND381 is a 4-channel AHD hard disk vehicle recorder with H.265, 1080P recording, a built-in G-sensor and 4TB SSD storage.
Detail Information
ND381 image 1
NDVR

ND381 4-Channel AHD Hard Disk Vehicle Recorder with G-Sensor

ND381

ND381 is a 4-channel AHD hard disk vehicle recorder with H.265, 1080P recording, a built-in G-sensor and 4TB SSD storage.

PositioningBuilt-in GPS / BeiDou / GLONASS (by version)
StorageSD card up to 512GB + 4TB SSD
Channels4-channel AHD vehicle recorder
Video Input1080P/720P/CVBS mixed input; AHD/TVI cameras
Video EncodingH.264 / H.265
Recording1080P (1920x1080)
↓ Request datasheet
  • 15-month warranty
  • IATF 16949 certified factory
  • OEM / ODM customization
  • Suitable for all vehicles

Final configuration is confirmed in your quotation.

Overview

What ND381 Delivers

ND381 is a 4-channel AHD hard disk vehicle recorder with H.265, 1080P recording, a built-in G-sensor and 4TB SSD storage.

ND381 unit
Overview

ND381 4-Channel AHD Hard Disk Vehicle Recorder with G-Sensor

ND381 is a 4-channel AHD hard disk vehicle recorder with H.265, 1080P recording, a built-in G-sensor and 4TB SSD storage.

  • Channels: 4-channel AHD vehicle recorder
  • Video Input: 1080P/720P/CVBS mixed input; AHD/TVI cameras
  • Video Encoding: H.264 / H.265
  • Recording: 1080P (1920x1080)
Models

NDVR Models

Compare ND381 with other models in this category. Each model has its own page.

ModelProductKey specVoltage
ND381this pageND381 4-Channel AHD Hard Disk Vehicle Recorder with G-SensorBuilt-in GPS / BeiDou / GLONASS (by version)—
ND380ND380 4-Channel AHD Hard Disk Vehicle RecorderBuilt-in GPS / BeiDou / GLONASS (by version)—
ND170ND170 4-Channel IPC Hard Disk Vehicle Recorder, No AHD1 SATA HDD up to 4TB + 1 SD card up to 1TB—
ND180ND180 Hard Disk Vehicle Recorder with Switch, 8 IPC and 4 AHD1 x 2.5" HDD/SSD + 1 TF card8-36V wide voltage, with overload, short-circuit and reverse-connection protection
ND310ND310 4-Channel AHD Vehicle Recorder with Dual TF CardsBuilt-in GPS / BeiDou / GLONASS (by version)—
ND320ND320 4-Channel AHD Vehicle Recorder with SD Card, 1080PBuilt-in GPS / BeiDou / GLONASS (by version)—
Specifications

Technical Specifications

Values follow the product page. Your quotation confirms the exact configuration.

Video and display

Channels
4-channel AHD vehicle recorder
Video Input
1080P/720P/CVBS mixed input; AHD/TVI cameras
Video Encoding
H.264 / H.265
Video Output
VGA + HDMI + CVBS
G-Sensor
Built-in

Connectivity and interfaces

Alarm I/O
4 alarm inputs, 2 alarm outputs
Positioning
Built-in GPS / BeiDou / GLONASS (by version)

Power and hardware

Storage
SD card up to 512GB + 4TB SSD
Warranty
15 Months

Other specifications

Recording
1080P (1920x1080)
Network
4G module and built-in WiFi (by version)
Protocol
JT808 / JT1078
System
Linux
Versions
ND381: local unit; -1 +GPS; -2 +GPS, WiFi; -3 and -4 +GPS, WiFi, 4G by region
Need the full engineering datasheet?Request the datasheet →
Downloads

Documents

Files that exist for this model can be downloaded. The others are available from our engineers on request.

Product datasheetOn request
Request
Certificates and test reportsOn request
Request
User manual and installation guideOn request · provided with sample orders
Request
FAQ

Frequently Asked Questions

Need technical clarification? Email safety@alwaycare.com or send an inquiry.

How is ND381 different from ND380?

ND381 adds H.265 encoding and a built-in G-sensor.

What storage does ND381 support?

An SD card up to 512GB plus a 4TB SSD.

Which warranty applies?

ND381 ships with a 15-month manufacturer warranty. Confirm final terms and regional service coverage in your quotation.
