APC (AI Passenger Counter)
Passenger-flow visibility
AI Passenger Counters for Bus and Transit Fleets
AlwayCare APC systems support passenger counting and listed passenger-type classification workflows. Choose a standalone 1- or 2-channel counter, a 4-channel MDVR-integrated kit or an 8-channel fleet-safety platform according to doors, camera coverage and system integration.
- Standalone and MDVR kits
- 1, 2 or 4 APC channels
- GPS and connected options
Choose the architecture
Standalone Counting or Recorder-Integrated Fleet Data?
Standalone 1-Channel
PC15 provides a focused single-channel APC starting point for bus fleets.
Standalone 2-Channel
PC16 expands standalone passenger-flow statistics to two APC channels.
4-Channel MDVR Kits
PC22, PC25, PC26 and PC28 combine recording with 1, 2 or 4 APC channels.
8-Channel Integrated Kits
PC36 and PC37 add two APC channels to an 8-channel MDVR architecture.
Operational workflow
Capture Boarding Events, Process Counts and Use the Data
Select APC Channels
Match counting-camera coverage to the required door layout.
Connect Context
Add positioning, 4G/Wi-Fi or MDVR recording when required.
Review Operations
Use supported passenger-flow data in the fleet workflow.
Channel terminology
APC Channels and MDVR Channels Are Different
“APC channels” describe passenger-counting inputs. “4CH” or “8CH MDVR” describes the wider recorder architecture. Confirm both values, the number of doors and all required safety functions before selecting a kit.
10 results
ViewShowcase
PC27 combines two-channel passenger counting, four-channel video, DMS, GPS/BeiDou and 4G or Wi-Fi connectivity.
PC37 combines 2-channel passenger counting with 8-channel video, DMS, ADAS, BSD, 4G and GNSS.
PC36 combines 2-channel passenger counting with 8-channel video, DMS, 4G and GPS/BeiDou/GLONASS.
PC28 combines 4-channel passenger counting with 4-channel video, 4G/Wi-Fi and 512GB SD storage.
PC16 is a standalone 2-channel AI passenger counter with 4G, GPS/BeiDou and CMS synchronization.
PC15 is a standalone single-channel AI passenger counter with 4G and GPS/BeiDou positioning.
PC26 combines 2-channel passenger counting, 4-channel video, DMS, 4G/Wi-Fi and GPS/BeiDou.
PC25 combines single-channel passenger counting with 4-channel video, 4G/Wi-Fi and GPS/BeiDou.
PC22 combines single-channel passenger counting with 4-channel video, 4G/Wi-Fi and optional DMS.
PC23 is a two-channel AI passenger counter with four-channel video monitoring, GPS/Beidou and 4G or Wi-Fi.
Nine-model selection table
Compare APC Architecture, Counting Channels and Integrations
Channel descriptions are taken from the current product records. Confirm camera quantity, door layout and the exact ordered functions before deployment.
| Model | Architecture | Listed APC channels | Other listed functions | Starting use case |
|---|---|---|---|---|
| PC15 | Standalone | 1 APC | GPS/BeiDou; 4G | Single-channel bus counting |
| PC16 | Standalone | 2 APC | GPS/BeiDou; 4G or Wi-Fi; I/O or RS232 optional | Two-channel passenger flow |
| PC22 | 4CH MDVR | 1 APC | GPS/BeiDou; 4G or Wi-Fi | Recording + one counting input |
| PC25 | 4CH MDVR | 1 APC | Listed DMS; GPS/BeiDou; 4G or Wi-Fi | Counting + driver monitoring |
| PC26 | 4CH MDVR | 2 APC | Listed DMS; GPS/BeiDou; 4G or Wi-Fi | Two APC inputs + DMS |
| PC28 | 4CH MDVR | 4 APC | GPS/BeiDou; 4G or Wi-Fi | Broader multi-door counting |
| PC36 | 8CH MDVR | 2 APC | Listed DMS; GPS/BeiDou/GLONASS; 4G | Expanded video + APC + DMS |
| PC37 | 8CH MDVR | 2 APC | Listed DMS/ADAS/BSD; GPS/BeiDou/GLONASS; 4G | Expanded fleet-safety kit |
| PC23 | School-bus kit | Confirm exact APC inputs | 8–36V; GPS/BeiDou; 4G or Wi-Fi | School-bus passenger workflow |
No universal counting-accuracy percentage is stated here. Validate performance for the actual door, lighting, passenger flow and installation.
Transit applications
Plan APC Around Doors, Routes and Fleet Operations
Route and Shuttle Services
Match counting channels to entry and exit points across scheduled or private services.
Multi-Vehicle Fleets
Standardize reporting needs while accounting for different door and vehicle layouts.
Connected Operations
Add positioning, wireless communication and MDVR context when fleet teams need centralized review.
Deployment checklist
What Should You Confirm Before Selecting an APC System?
How many doors and flows?
Map boarding and alighting points, simultaneous movements and the required APC camera coverage.
Standalone or MDVR-integrated?
Choose standalone counting for a focused project or an MDVR kit when recording and safety functions are also required.
Which data connection?
Confirm 4G or Wi-Fi, positioning, optional I/O/RS232 and the expected platform workflow.
How will performance be validated?
Test the installed system against real doors, lighting, crowd flow and operational reporting rules.
Direct answers
AI Passenger Counter FAQ
What is an AI passenger counter?
It is a vehicle system that processes camera input to count passenger movements and, for listed models, support passenger-type classification workflows.
Which models are standalone?
PC15 is the listed one-channel standalone option and PC16 is the listed two-channel standalone option.
Which model supports the most listed APC channels?
PC28 is listed as a 4-channel MDVR with four APC channels.
Which kits also list DMS?
PC25, PC26, PC36 and PC37 list DMS. PC37 additionally lists ADAS and BSD in its product title.
Is counting accuracy guaranteed for every bus?
No universal percentage is stated on this page. Results should be validated for the actual camera position, doors, lighting and passenger-flow conditions.
Configure the complete APC workflow
Match Counting Channels to Doors and Fleet Data Needs
Share the vehicle type, number of doors, passenger flows, recording, positioning, connectivity and platform requirements for a focused recommendation.
