Commercial reliability
Engineered for high vibration, wide voltage fluctuations, and continuous fleet duty.
MR910-DAB1 5-Channel AI MDVR Telematics Terminal (DMS + ADAS + BSD)
| Share | |
|---|---|
| Categories | AI MDVR |
| Brand | AlwayCare Commercial Fleet Safety Manufacturer |
| Model | MR910-DAB1 |
| Channel Capacity | 5 Channels (4 AHD + 1 IPC) |
| AI Algorithm Suite | DMS + ADAS + BSD Multi-Algorithm |
| Video Compression | H.264 / H.265 High Efficiency |
| Storage Support | Dual SD Slots up to 512GB |
| Wireless Connectivity | 4G LTE + GPS/BDS + Wi-Fi |
| Operating Voltage | DC 9V - 36V Vehicle Power |
| Operating Temperature | -20℃ ~ +70℃ |
| Compliance | CE, FCC, RoHS, UN R151 Ready |
Detail Information
MR910-DAB1 · Commercial fleet safety
What is MR910-DAB1?
Flagship 5-channel AI mobile DVR combining DMS driver monitoring, ADAS forward collision warning, and BSD blind-spot detection with 4G/GPS fleet telematics CMS integration.
Fast evaluation
Four points to confirm first
Clear visibility
Delivers crisp video clarity for in-cab reversing, multi-view surveillance, and blind spot awareness.
DC 9-36V wide voltage
Standardized vehicle electrical system compatibility with built-in surge protection.
Locking aviation connector
Threaded 4-pin aviation connection prevents signal dropouts during rugged road operations.
Verified capabilities
How MR910-DAB1 supports fleet operations
Accident prevention
Provides critical real-time visual support to prevent maneuvering and backing collisions.
Easy in-cab fit
Compact and rugged form factor designed for straightforward dashboard or windshield mounting.
All-weather durability
Withstands severe heat, cold (-20°C to +70°C), and cabin dust without performance degradation.
Turnkey integration
Seamlessly pairs with AlwayCare cameras, MDVR recorders, and power harnesses.
Factory specifications
Technical specifications
| Model Designation | MR910-DAB1 |
|---|---|
| System Architecture | 5-Channel AI MDVR Gateway (4 AHD + 1 IPC) |
| AI Algorithm Suite | DMS (Fatigue) + ADAS (Collision) + BSD (Blind Spot) |
| Video Compression | H.264 / H.265 High Efficiency |
| Storage Support | Dual SD Slots up to 512GB |
| Wireless Connectivity | 4G LTE (Full Netcom) + Dual-Mode GPS/BDS + Wi-Fi Hotspot |
| Operating Voltage | DC 9V – 36V Vehicle Power with Ignition Delay |
| Operating Temperature | -20℃ ~ +70℃ |
| Compliance Standards | CE, FCC, RoHS, ISO9001, UN R151 / BSIS Ready |
Specifications describe standard AlwayCare factory configurations. Custom connectors, cable lengths, and private-label OEM options are fully supported in volume quotations.
Deployment examples
Where MR910-DAB1 fits
City Buses & Rapid Transit
In-cab active DMS fatigue coaching paired with passenger door surveillance for zero passenger accidents.
School Bus Fleets
High-definition 1080P multi-view recording preserves clear evidence of child boarding and drop-off zones.
Intercity Coaches & Shuttles
ADAS forward collision warnings assist drivers during monotonous highway night routes.
Project planning
What should be confirmed before installation?
Use this checklist to align hardware options, interface types, and vehicle layout before deployment.
- 1
Confirm vehicle operating voltage (12V / 24V / 36V / 90V).
- 2
Select required camera channels and cable lengths (5M / 10M / 15M / 20M).
- 3
Determine mounting location (A-pillar, dashboard bracket, or windshield suction mount).
- 4
Calibrate camera viewing angles and verify reverse trigger line connections.
Safety and configuration boundary
MR910-DAB1 provides driver visual assistance and active alerts; operators must maintain vigilance and follow standard commercial driving safety protocols.
Buyer questions
MR910-DAB1 FAQ
Is MR910-DAB1 compatible with existing fleet electrical systems?
Yes, it supports DC 9V to 36V wide voltage input with built-in surge protection, making it compatible with 12V vans, 24V trucks, and industrial equipment.
What connector type is used?
Standard versions utilize 4-Pin aviation screw-locking connectors for vibration resistance. RCA adapters and custom harnesses are available upon request.
Can I request custom branding or OEM packaging?
Yes. AlwayCare provides complete OEM/ODM solutions including customized startup logos, silkscreen housing branding, and tailored accessory packaging for volume orders.
Build the correct configuration
Share your vehicle and fleet requirements
Tell AlwayCare your vehicle model, fleet size, camera channel preferences, and custom project requirements for a competitive factory quote.
